305801 C-2Z, SKF, Cam roller (yoke-type track roller) with flat outside surface

Metric, Complete track roller, Metal shield on both sides, Cylindrical profile, Normal (except crowned running surface), EAN code: 07316577742698

SKF
Brand SKF
Mfr Part No. 305801 C-2Z
Acorn Code 305801C-2Z-SKF
HS Code 8482 40 00 00
COO Bulgaria (BG)

$34.33

+
in stock

Cam roller (yoke-type track roller) with crowned outside surface, integral sealing and relubrication feature

These cam rollers (yoke-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on double row angular contact ball bearings. They have a thick-walled outer ring with a crowned running surface prevents edge stresses under skewing. They are supplied greased, sealed and ready-to-mount. A lubrication hole in the inner ring facilitates relubrication.

• High radial load carrying capacity and relatively high speed capability
• Accommodate tilting moments
• Long service life
• Ready to mount
• Integral sealing, for increased reliability, with relubrication feature

Specification

Product Attributes
Manufacturer Product Code 305801 C-2Z
Basic Product Description Cam roller (yoke-type track roller) with flat outside surface
Measurement Metric
UOM Each
id (mm) 12
od (mm) 35
Width (mm) 15.9
Number of Rows 2
Weight (Kg) 0.07
Sealing Metal shield on both sides
Features Non-contact sealing type
Features Relubrication feature Via inner ring lubrication hole
Outer ring profile Cylindrical profile
Accuracy Normal (except crowned running surface)
Bearing Material Bearing Steel
Basic dynamic load rating 9.04 kN
Basic static load rating 4.555 kN
Limiting speed 9500 r/min
EAN-Code 07316577742698
