Overcoming coupling failure and maximising productivity

When the weather starts to turn, reviewing the condition and suitability of your machinery’s couplings can help prevent unespected distruption. Coupling failure can have a serious impact on productivity levels and choosing the right one is the difference between reliability or operational disruption.

As part of your autumn and winter maintenance preparations, it is worth checking that your couplings remain suitable for the loads, alignment and environmental conditions they will face. Here, Jason Buck, Power Transmission Product Manager a ACORN, talks about the top three considerations for minimising coupling failures and keeping machinery running reliably through the colder months.Get your free printable autumn maintenance checklist

Top consideration factors for coupling longevity

Spend any time in the world of couplings and you will know that there are a lot to choose from! With over twenty widely used coupling types and many more sub-variants and bespoke solutions, the ‘right’ coupling will be the one that meets that machine, environment or industry’s specific needs.

Autumn provides a useful opportunity to review those requirements, particularly for machinery exposed to outdoor conditions or operating in unheated areas. Over my years supplying couplings for a wide range of applications, there are three considerations that I see as priorities when looking to promote coupling reliability and longevity.

Does it have a sufficient torque rating and operate within misalignment parameters?

One of the most common reasons for coupling failure that I see in my working day are couplings that have not been selected with sufficient torque rating. By not identifying a suitable coupling that can withstand the torque being transferred through the drive, issues can occur.

Also, although couplings can help manage shaft misalignment issues between the motor and driven machine, if they aren’t properly selected this can lead to premature failure, increased bearing and seal loads and reduced machine accuracy. All these things will, over time, lead to a situation of unplanned maintenance, potential damage to connected equipment and costly downtime. It can also be costly to replace a damaged coupling, and this is an unnecessary and unwanted expense if the proper coupling selection procedures are not followed.

In an ideal world shafts would be perfectly aligned but that is rarely the case. That is why flexible couplings that resolve angular and radial misalignment issues and axial movement are so popular. However, whether it is a jaw, beam, disc gear or grid coupling, if the misalignment parameters of the coupling have been exceeded, then issues will occur.

So, the second common reason for coupling failure that I see is the under-estimation of the degree of misalignment. This creates loads that surpass the coupling’s specifications, causing it to wear at an accelerated rate. The result is bearing and shaft wear, noise, vibration and premature coupling and machine failure. If the shaft misalignment is greater than the coupling’s operational limits, then it will need to be realigned before coupling installation is undertaken, otherwise repeat failures and more production downtime will be the result.

Is it the right coupling for the right application?

The third area of premature coupling failure that I deal with a lot is due to the wrong coupling being used in the wrong application. Understanding application requirements is key to choosing the right coupling solution, as well as the environmental conditions it will be exposed to. Several criteria must be considered when deciding on a type of coupling, including the type of application, misalignment, stiffness, inertia, RPM, shaft mounting, environmental factors, space limitations, service factors, and cost.

For autumn and winter preparation, pay particular attention to operating temperatures and exposure to moisture. Check that the coupling and any flexible elements are suitable for the expected temperature range, especially on outdoor machinery or equipment in unheated buildings.

Mistakes in coupling selection can also be exacerbated by a lack of consideration for torsional compliance (or windup), backlash, not considering the dampening levels required, or underestimating the torque for an application. Taking torque as an example, the maximum instantaneous torque for an application needs to be considered, in addition to the steady-state torque. Flexible couplings have different static torque ratings depending on the design type. For example, a double disc coupling will typically offer a 15-20% higher static torque rating than an identically sized Oldham coupling with an acetal disc. It is therefore important that each criterion impacting coupling choice must be individually assessed to ensure that the end solution is fit for purpose and the process must also be repeated for any change in conditions throughout the application’s lifecycle.

However, the world of couplings is vast, and it is difficult to keep up to speed with the variety of options available and which would be the best fit for each application. As a supplier of a wide range of manufacturers couplings, from Falk and KTR to Rexnord, Flender, Centa and Protorque, a lot of our team’s time is spent running calculations across manufacturers’ products. When we do this, we are assessing the application’s power, speed and shaft size requirements, as well as the driving and driven equipment, the shaft gap, room envelope size and any shock loading issues. We also need to assess environmental factors, availability and price.

Although the right choice of coupling can be complex, checking under-torquing and over-misalignment and confirming the suitability for the operating environment can help minimise premature failure and maximise service life. By including these checks in your autumn and winter preparations, and drawing on manufacturers’ and suppliers’ expertise where needed, you can address developing issues and help keep machinery running reliably through the months ahead.
