NN3036-AS-K-M-SP, FAG, Super precision cylindrical roller bearing, Double-row design

Bearing, Brass Cage, C1 clearance, EAN code: 4012801017367

ACORN is an FAG Authorised Distributor
Brand FAG
Mfr Part No. NN3036-AS-K-M-SP
Acorn Code NN3036-AS-K-M-SP-FAG
HS Code 8482 50 00 90
COO

Country of Origin details on this platform are for reference only and may differ from the actual products supplied. This information does not guarantee preferential treatment or availability from a specific country.

 Germany (DE)

$2,266.77

− +

Super precision cylindrical roller bearings NN30..-AS-K-M-SP, non-locating bearing, double row, with tapered bore, taper 1:12, separable, with cage

Specification

Product Attributes
Manufacturer Product Code NN3036-AS-K-M-SP
Basic Product Description Super precision cylindrical roller bearing, Double-row design
Measurement Metric
UOM Each
id (mm) 180
od (mm) 280
Width (mm) 74
Weight (Kg) 16.2
Bore Type Tapered, taper 1:12
Clearance C1 clearance
Tolerance group Class (SP)
Cage Material Brass Cage
Basic dynamic load rating 570000
Basic static load rating 1000000
Fatigue load limit, radial [C ur] 118000
Limiting speed 2850
EAN-Code 4012801017367
