Gas cell producing gas, Single point automatic lubricator
The simalube IMPULSE connect is the latest generation of the pressure booster from the simalube family. The proven functions of the IMPULSE have been supplemented with the option of connecting the device to a smartphone via Bluetooth®. In connection with the newly developed «simatec world of maintenance» app, the devices can be easily configured and then monitored without having to be directly at the lubrication point. Information such as general status, fill level, lubricant, size, start and change date etc. is displayed to the user and easy to read in the app. It also enables the customer to manage the lubrication points digitally.
| Manufacturer Product Code | 230-10100 |
|---|---|
| Basic Product Description | simalube IMPULSE connect, Pressure booster 60-250ml. Bluetooth 5.0 |
| Product type | Single point automatic lubricator |
| Drive Mechanism | Gas cell producing gas |
| Connection thread | G 1/4 |
| Intrinsically safe approval | II 1 G Ex ia IIC T6 Ga II 1 D Ex ia IIIC T200 80 °C Da I M1 Ex ia I Ma |
| Ambient temperature range | -20 °C to +55 °C |
| Maximum operating pressure | 5 bar |
| Lowest grease purge | 0.04 ml per day |
| Highest grease purge | 8.3 ml per day |
| Environmental protection | IP 68 |
| Nominal emptying time | Adjustable; 1-12 months |
