TLDD 2/EU-DS, SKF, SKF TLDD Drive unit, plastic cap and support plate

Electro mechanical

SKF Authorised distributor logo
Brand SKF
Mfr Part No. TLDD 2/EU-DS
Acorn Code TLDD2/EU-DS-SKF
HS Code 2710 12 15 00
COO

$202.46

+

Connected TLDD drive unit (including support plate for grease) - European version
European version of the wireless connected drive unit, including support plate for grease. Assembled with a dedicated TLSD lubricant cartridge (to be ordered separately) it makes a connected TLDD single-point automatic lubricator. Via a wireless connection to the TLDD Gateway it will display 24/7 its working condition on the associated SKF web-interface. Allows use of a wide range of lubricants.
Wireless connection allows monitoring and control of the lubricator 24/7 from any place
Compact size permits installation in restrictive areas
Supplied with support flange for enhanced sturdiness
Suitable for both direct and remote installation
Suitable for use with all grease and oil TLSD refill sets when installed with correct support flange
Maximum discharge pressure of 5 bar over the whole dispensing period
Emptying time options extended up to 24 months

Specification

Product Attributes
Manufacturer Product Code TLDD 2/EU-DS
Basic Product Description SKF TLDD Drive unit, plastic cap and support plate
Weight (Kg) 0.323
Drive Mechanism Electro mechanical
Connection thread G 1/4
Special features Monitoring of the lubricator status possible both remotely (Lubrication Cloud platform) and in the field (LED)
Maximum Allowable Working Pressure 5 bar
Data frequency range (LoRa) 863.0 - 870.0 MHz
Battery packs TLSD 1-BAT
Maximum feed line length 3 mtr (Grease) 5 Mtr (Oil)
Environmental protection IP 65
Nominal emptying time 1 to 24 month, adjustable via Lubricator Control Panel
